Trilium is a self-hosted, single-user note taking application. Trilium server is a web application which provides responsive UI for note taking. The desktop client synchronises with the server. It does not have mobile app, but it has a mobile web frontend which is optimized for touch based devices - smartphones and tablets.
In this post I will provide instruction for hosting the server application in Arch Linux.
Prerequisites:
Docker is installed and running.
Install
docker-compose
package.Add yourself to
docker
user group.
sudo usermod -a -G docker <username>
Prepare Docker Compose File
Create a docker-compose.yaml
file. You can save it in any folder you like, mine is kept in ~/dev/docker/trilium/
.
services:
trilium:
image: 'zadam/trilium:0.63.7'
restart: always
ports:
- '8080:8080'
volumes:
- '~/.trilium-data:/home/node/trilium-data'
The container will be listening on port 8080. If you want to change the port number to 3000, set the ports
configuration value to '3000:8080'.
I want the note data to be saved in ~/.trilium-data/
. If you prefer other location, change the volumes
configuration value to '/path/to/your/folder:/home/node/trilium-data'.
Create And Start Container
# Go to folder containing compose file
cd ~/dev/docker/trilium
docker-compose up -d && docker-compose logs -f
docker-compose logs -f
command is optional. It will show the log output so that you can check if there is any error when launching the container. Once Trilium is running well, you can press Ctrl + C to exit from the logging.
Trilium shall be accessible by launching http://<you-server-ip>:8080 in browser. Choose "I'm a new user, ..." on the webpage, and it will guide you to setup a password and get started on note taking.
Setup Apache Reverse Proxy
This setup is optional. I am running Trilium in my home server with Apache web server installed. Setting up a reverse proxy allows me to access Trilium remotely.
Apache virtual host config:
<VirtualHost *:80>
ServerName www.mydomain.com
RewriteEngine On
RewriteCond %{HTTP:Connection} Upgrade [NC]
RewriteCond %{HTTP:Upgrade} websocket [NC]
RewriteRule /(.*) ws://localhost:8080/$1 [P,L]
ProxyPreserveHost On
ProxyPass / http://127.0.0.1:8080/
ProxyPassReverse / http://127.0.0.1:8080/
</VirtualHost>
References
Trilium Notes - Open Source, Self Hosted Notes with nth level Hierarchy and Power! by Awesome Open Source
Docker server installation by zadam
Apache proxy setup by zadam
